Modbus configurator blue'Log XM/XC

Create blue’Log specific Modbus drivers.

Description

All connected devices require a driver to communicate with the blue'Log XM/XC. meteocontrol provides an "all-in-one" driver for standardized communication interfaces, which is continuously updated. For all supported devices, see Compatibility Check.

In addition to the all-in-one driver, you can create blue’Log-specific Modbus driver profiles via the blue’Log web interface. The Modbus Configurator blue’Log XM/XC allows you to implement project- or device-specific Modbus mappings.

The Modbus profiles you create are not part of the blue’Log all-in-one driver package and are only available on the specific blue’Log device where they were created.

Features

• Creation of blue’Log-specific Modbus drivers via the blue’Log web interface with detailed, step-by step configuration help

• Multiple Modbus profiles on a single blue’Log

• Modbus profiles are based on the available blue’Log device categories: Inverter ¹⁾, Sensor, Meter, String monitoring, Status DI external, Tracker, Battery, Genset. For the max. number of values available for each device category, see our Import specification.

• Download of Modbus profiles as a .JSON file

• Import of existing Modbus profiles

¹⁾ Inverter driver profiles created with the help of the Modbus configurator can not be used for Power Control.

Requirements

• Basic knowledge of MODBUS (https://modbus.org)

• blue’Log XM/XC

• Firmware ≥ 17.0.11

• Modbus configurator blue’Log XM/XC license. The license is issued for a specific blue’Log XM/XC. When ordering, provide the 14-digit hardware serial number of your data logger.
