i’catcher 8-8
-
i’catcher 8-1B
-
i’catcher 16-1Bi’catcher 24-1B (Modbus RTU)
-
Set the bus address on the i'catcher (see i'catcher documentation).
-
If the device is the last one on the RS485 bus, set the terminating switch (Term.) to "On". Since the i'catcher 8-8 has no terminating switches, the bus must be terminated regularly with a 120 Ω resistor between wires A and B.
-
Various Modbus devices can only be queried together if the serial communication parameters are identical (baud rate, number of data bits, parity, stop bits).
|
Description |
|
|---|---|
|
1 |
Data logger terminal, RS485 |
|
2 |
First and subsequent i’catchers |
|
3 |
Last i’catcher |
