Hukseflux SR20-TR
Last modified:
Pyranometers can be used to measure irradiance either in horizontal or module plane.
Hukseflux SR20-TR: Sensor connection
Description | |
|---|---|
| 1 | Data logger terminal, digital output/multi-input |
| 2 | Data logger terminal, Power Out |
| 3 | Pyranometer |
Connection
Wire color | Use |
|---|---|
White | Irradiance signal power supply (7.2 … 35 V DC) |
Green | Irradiance signal (4 … 20 mA) |
Red | Temperature signal (PT100, 4-wire configuration) |
Blue | Temperature signal (GND, 4-wire configuration) |
Pink | Temperature signal (PT100, 4-wire configuration) |
Grey | Temperature signal (GND, 4-wire configuration) |
Yellow | Power supply for heater (not controlled) |
Brown | Heater GND (not controlled) |
Black | Shield |
Configuration data
Measurement | Input | Unit | Gradient | Offset |
|---|---|---|---|---|
Irradiance on horizontal plane | Analog 4…20 mA | W/m2 | 100 | -400 |
Irradiance on module plane | Analog 4…20 mA | W/m2 | 100 | -400 |
