Weidmüller Transclinic xi+1
Last modified:
Set the bus address and make the serial RS485 settings on the Transclinic (see Transclinic documentation).
If the device is the last one on the RS485 bus, terminate the bus with a 120 Ω terminating resistor.
Various Modbus devices can only be queried together if the serial communication parameters are identical (baud rate, number of data bits, parity, stop bits).
Weidmüller Transclinic xi+: String monitoring connection
Description | |
|---|---|
| 1 | Data logger terminal, RS485 |
| 2 | First and subsequent Transclinic (Example: Transclinic 14i+) |
| 3 | Last Transclinic (Example: Transclinic 16i+) |
| 4 | Terminating resistor |
