Kipp & Zonen SMP3, SMP10, SMP11 (analog interface)
Last modified:
Pyranometers can be used to measure irradiance either in horizontal or module plane.
Kipp & Zonen SMP3, SMP10, SMP11 (analog interface): Sensor connection
Description | |
|---|---|
| 1 | Data logger terminal, digital output/multi-input |
| 2 | Data logger terminal, Power Out |
| 3 | Pyranometer |
Connection
Wire color | Use |
|---|---|
Black | GND |
White | Power supply (5 … 30 V DC) |
Brown | Irradiance signal GND |
Green | Irradiance signal (4 … 20 mA) |
Gray | RS485 Modbus interface B (-) |
Yellow | RS485 Modbus interface A (+) |
Blue | RS485 Modbus interface GND |
Red | Not used |
Configuration data
Measurement | Input | Unit | Gradient | Offset |
|---|---|---|---|---|
Irradiance on horizontal plane | Analog 4…20 mA | W/m2 | 100 | -400 |
Irradiance on module plane | Analog 4…20 mA | W/m2 | 100 | -400 |
